Pinbelegung
Alle
| Funktion | Pin |
| Uart TX | 14 |
| Uart RX | 27 |
LuAIsa
| Funktion | Pin |
| SPI SCLK | 22 |
| SPI MOSI | 21 |
| SPI CS | 5 |
| RS | 19 |
| RST | 18 |
| Encoder A | 39 |
| Encoder B | 36 |
| Taster Schwarz | 12 |
| Taster Weiß | 33 |
| Taster Rot | 32 |
| Taster Blau | 25 |
Luisa
| Funktion | Pin |
| I2C sda | 21 |
| I2C scl | 22 |
| Encoder A | 18 |
| Encoder B | 19 |
| Encoder Taster | 5 |
